Aerial SNE CNE Cable is used for house connections. Split concentric cable suitable for power distribution as an underground or overhead cable. LEAVE MESSAGE SEND E-MAIL
Aerial SNE(Seperate Neutral & Earth) CNE(Combined Negative & Earth) Cable is used for house connections. This cable can only be used for single phase supply. Cable is made to be suspended in the air. Aerial SNE Cable is also suitable for underground general use, sub main distribution boxes, street lighting systems and high rise buildings. Split concentric cable suitable for power distribution as an underground or overhead cable.
SANS 1507/6
| Size | Phase Conductor | XLPE Insulation | Earth Conductor | PE Sheath | Approx. Weight | ||||
| Structure | O.D | Thickness | O.D | Structure | O.D | Thickness | O.D | ||
| mm2 | No./mm | mm | mm | mm | No./mm | mm | mm | mm | kg/km |
| 4 | 7/0.92 | 2.76 | 1.0 | 5.97 | 8/0.85 | 6.46 | 1.4 | 9.41 | 131 |
| 10 | 7/1.35 | 4.05 | 1.0 | 5.22 | 18/0.85 | 7.75 | 1.4 | 10.70 | 240 |
| Size | Phase Conductor | XLPE Insulation | Earth Conductor | Neutral Conductor | Pilot Core | PE Sheath | Approx. Weight | |||
| Structure | O.D | Thickness | O.D | Structure | Structure | Structure | Thickness | O.D | ||
| mm2 | No./mm | mm | mm | mm | No./mm | No./mm | No./mm | mm | mm | kg/km |
| 4 | 7/0.92 | 2.76 | 1.0 | 5.97 | 3/1.05 | 7/0.86 | 2/1.13 | 1.4 | 10.0 | 168 |
| 10 | 7/1.35 | 4.05 | 1.0 | 5.22 | 3/1.78 | 7/1.33 | 2/1.13 | 1.6 | 12.7 | 334 |
| 16 | 7/1.70 | 5.10 | 1.0 | 7.10 | 3/2.20 | 7/1.67 | 2/1.13 | 1.6 | 14.5 | 502 |
Scroll horizontally to review complete specification columns.
Request Full TDSAerial SNE CNE Cable is used for house connections. Split concentric cable suitable for power distribution as an underground or overhead cable. LEAVE MESSAGE SEND E-MAIL
Product image and technical reference.
